Eames elegant lounge chair|EAMES leisure chair manufacturing|Hebei Mudasen wooden furniture proces-DN17 Stadium grandstand seat

‍

Product features; gas-assisted injection molding, split seats, spring dump, hanging installation

Main material; polypropylene (PP), high-strength aluminum alloy, hot-rolled plate, hot-rolled profiles

Size parameters; width X deepth X height 450X420X800

Using venue; all kinds of indoor field, museum

Installation requirements; step height 280mm - 650mm, step width ≥ 800mm, center distance

470mm-510mm

Additional features; handrails, cushions, cup holder, antistatic

‍

Seat with shared handrails, split flap seat. The foot is made of aluminum alloy die-casting,

the surface of the phosphating treatment after the spray (or paint) treatment, never rust,

with M10 × 80 expansion bolts and stadium stands fixed. Seat color according to user selection.

Installation: side hanging type, flat ground floor type

Size: seat height 800mm, seat cushion depth 420mm, cushion width 450mm

Cushion chair surface 450 × 420mm seat back pad width 440mm back pad height 446mm back cushion 440 × 446mm

Center distance: 470 ~ 500mm

Style: split seat (flap chair), chair spring return (near the back), chair legs can even arm

Appearance: nice, comfortable seat, reasonable structure, strong strength

Ingredients: Polypropylene M02

Chair: high-quality aluminum die-casting forming, installation; vertical, hanging, (with spring flip).

Fixed: M10 × 80 expansion bolts fixed

‍

Seat installation diagram
